Elau C200/10/1/1/1/00 Servo Controller

Description

Product Introduction

The Elau / Schneider Electric PacDrive C200 (Part No. C2001011100) is a compact, high-performance programmable motion controller built explicitly for synchronized multi-axis packaging machinery, robotics, and converting systems. Driven by an ST-PC Vega processor architecture, it merges PLC logic execution and motion control into a single unified hardware platform, eliminating traditional motion bus latency.

Unlike standard modular PLCs, the C200 series integrates drive control and centralized logic processing with deterministic performance profiles. Its onboard memory capacity (128 MB RAM / 32 MB Flash) handles complex camming, gearing, and robotics kinematics algorithms natively, ensuring high-speed track-and-trace accuracy on high-throughput production lines.

Key Technical Specifications

Application Scenarios & The “Trench” Experience

A high-speed vertical form-fill-seal (VFFS) packaging line suffers an unexpected controller crash right in the middle of a peak Monday production run. The screen goes dark, communication drops across the PacDrive network, and diagnostics point to a fried motherboard on the legacy C200 controller rack due to an internal power supply surge. The plant faces thousands of dollars per hour in downtime penalties. Pulling the bad unit and sliding in a pre-configured, tested C2001011100 replacement—followed by an immediate project download via EPAS-4—brings the motion loops back online and resumes packaging within minutes.

Specific Application Scenarios:

• Packaging Machinery: Synchronizing multi-axis rotary knife cutters, auger fillers, and film-feed stepper/servo axes.
• Converting & Printing: Controlling high-precision registration marks, web tensioning, and electronic gearing shafts.
• Robotics & Pick-and-Place: Executing multi-axis kinematic transforms for high-speed delta and scara robots.
• Material Handling: Indexing conveyors and synchronized grouping belts requiring sub-millisecond execution.

C200/10/1/1/1/00

C200/10/1/1/1/00

Transparency SOP: Quality Assurance & Testing

Every Elau C2001011100 unit sourced for our inventory passes through a stringent multi-point test bench protocol before release:

1. Inbound Physical Inspection: Verification of housing integrity, optical connector ports, backplane pins, and original manufacturer security/anti-tamper seals.
2. Static Bus & Power Check: Resistance testing across the 24V DC power input terminals to verify absolute immunity from short circuits or damaged internal filtering capacitors.
3. Firmware & Boot Execution: Powering up the controller on a dedicated PacDrive test rack to verify POST (Power-On Self-Test) sequences, internal battery voltage levels, and BIOS stability.
4. Communication & Port Verification: Establishing a live connection via Ethernet and serial interfaces to validate data packet transmission and memory read/write cycles across the 128MB RAM block.
5. Thermal Run-In: Running a continuous 2-hour burn-in cycle under load to monitor thermal dissipation and ensure zero component drift.
6. ESD Shielding & Packing: Sealed in industrial-grade antistatic packaging materials with custom dense foam reinforcement to guarantee safe transport.

The Veteran’s Tech Trap Guide

⚠️ 1. Back Up Your Flash Card and NVRAM First

Never hot-swap or replace a C200 controller without backing up the project files and system configuration using EPAS-4. If the CompactFlash card or internal battery backup fails during a swap, you will be left with a blank controller and a machine that won’t run a single cycle.

❗ 2. Verify Firmware Revision Mismatches

Do not assume a drop-in C2001011100 replacement will instantly accept your existing binary if the firmware versions mismatch. Always check the target firmware revision in the CoDeSys/EPAS environment and flash the controller to match your exact machine software version before initial commissioning.

⚠️ 3. Watch Out for 24V DC Power Supply Ripple

The ST-PC Vega processor and internal communication cards on the C200 are exceptionally sensitive to power supply noise and voltage sags. Ensure your cabinet’s 24V DC switched-mode power supply is regulated tightly; a noisy supply will cause random watchdog timeouts and unexplainable motion faults.

Frequently Asked Questions

Q: Is the Elau C2001011100 hot-swappable?

A: No. Disconnecting or sliding out this controller card while the 24V DC cabinet power is active can cause severe electrical arcing, corrupt memory registers, and fry onboard interface chips. Always execute LOTO procedures prior to handling.

Q: Can I use standard PC memory upgrades in this controller?

A: No. The system memory architecture (128 MB RAM / 32 MB Flash) is proprietary to the Elau PacDrive hardware configuration. Standard commercial RAM modules are incompatible and will cause boot failure codes.

Q: Why is a surplus C2001011100 recommended over a full control system migration?

A: Migrating an older Elau PacDrive system to a modern Schneider PacDrive 3 platform requires rewriting the entire PLC code base, replacing servo drives, and re-pinning cabinet I/O. Dropping in an exact-match tested surplus C200 controller restores legacy operation immediately with zero software downtime.

Q: What kind of warranty is included with this unit?

A: We supply all tested New Surplus and refurbished Elau automation hardware with a comprehensive 12-month functional replacement warranty.
