Metso D201291 | ACN SR1 Small Rail-Mounted Controller

Description

Core Product Summary (Brand / Model / Key Attributes)

The Metso D201291 is an ACN SR1 small rail-mounted controller used within the Metso DNA automation platform. It provides compact process control capability for applications that require a space-efficient controller node mounted on a DIN rail or similar rail system.

The module is designed for field or cabinet installation and supports the control, I/O, and communication functions of the ACN SR1 series within the DNA distributed control architecture.

Key Technical Specifications

Detailed Product Overview

The Metso D201291 belongs to the ACN SR1 family of compact controllers in the Metso DNA automation system. ACN SR1 nodes are designed for installations where a full rack-mounted controller is not required, offering a smaller footprint suitable for distributed or local control tasks.

The D201291 functions as a process control node capable of executing control logic, handling associated I/O, and communicating within the DNA network. It is typically mounted on a standard industrial rail and integrates with other DNA system components such as I/O modules, operator interfaces, and higher-level engineering tools.

Because it is a system-specific controller, configuration and application programming are performed using Metso DNA engineering software. Power, communication, and I/O connections follow the standards defined for the ACN SR1 series. Correct identification of the exact node type and system revision is required before replacement or expansion.

The module is intended for continuous industrial operation and forms part of the scalable control hierarchy of the DNA platform, ranging from small local nodes to larger plant-wide systems.

System Compatibility & Integration Requirements

Engineering Selection Highlights

• Compact ACN SR1 rail-mounted controller for Metso DNA systems.
• Suitable for distributed or space-constrained control applications.
• Executes process control logic and supports associated I/O within the DNA architecture.
• Integrates with Metso DNA engineering tools for configuration and diagnostics.
• Direct replacement or expansion part for matching ACN SR1 installations.

D201291

D201291

Dimensions, Mounting & Connection Notes

The D201291 is a compact rail-mounted module designed for installation on a standard industrial DIN rail or equivalent. Power, fieldbus, and I/O connections are made according to the terminal and connector arrangement of the ACN SR1 series. Adequate clearance for ventilation and cable routing must be maintained.

FAQ

What is the Metso D201291?
It is an ACN SR1 small rail-mounted controller used in the Metso DNA automation system.

What is the ACN SR1 series?
A compact controller family within Metso DNA designed for rail mounting and distributed control applications.

Is it a full rack controller?
No. It is a small form-factor, rail-mounted node intended for more compact installations.

Which software is used for configuration?
Metso DNA engineering tools.

What must be verified before replacement?
That the host system uses an ACN SR1 node and that the order code matches D201291.

Verification & Troubleshooting Notes

• Confirm the module is marked D201291 and identified as an ACN SR1 controller.
• Verify compatibility with the existing Metso DNA system revision and network configuration.
• Follow Metso DNA procedures for safe removal, installation, and power-up of controller nodes.
• After installation, check node status and communication through the DNA engineering tools.
• Ensure all power, communication, and I/O connections are correctly restored according to the system documentation.
