Description
Product Introduction & Engineering Value
When operators lose visibility into a production line, troubleshooting becomes guesswork. The ABB CP676 was designed to provide a reliable operator interface for machine builders and process engineers who require clear visualization, responsive touch operation, and dependable communications with PLCs and automation devices.
Part of ABB’s CP600 family, the CP676 supports applications developed with Panel Builder 600 (PB610) and communicates with ABB AC500 PLCs as well as many third-party controllers through multiple industrial communication drivers. Its large display makes it particularly suitable for applications requiring detailed process graphics and extensive alarm information.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | CP676 |
| Article Number | 1SAP576100R0001 |
| Product Family | CP600 Series |
| Display Size | 15 inches |
| Display Resolution | 1024 × 768 (XGA) |
| Display Type | TFT LCD, 64K Colors |
| Touch Technology | Single-Touch Resistive Screen |
| Operating System | Windows Embedded CE 6.0 Core |
| Runtime Software | PB610 Runtime License |
| Ethernet | 2 × 10/100 Mbps RJ45 |
| Serial Interface | 1 × RS-232/RS-422/RS-485 |
| USB | 2 × USB 2.0 Host |
| Expansion | 2 Expansion Slots, 1 SD Card Slot |
| Front Protection | IP66 |
| Rear Protection | IP20 |
| Supply Voltage | 24 VDC |
| Operating Temperature | 0°C to +50°C |
| Mounting | Front Panel Mount |
| Typical Weight | Approximately 3.6 kg |
Field Application & The “Trench” Experience
A steel processing facility experienced repeated production delays because operators could no longer acknowledge alarms on an aging 15-inch HMI. The PLC continued executing the process correctly, but deteriorating touchscreen performance forced technicians to operate equipment manually during maintenance shifts.
Instead of replacing the control system, engineers installed a replacement ABB CP676, restored the existing Panel Builder 600 project from backup, and completed commissioning in less than two hours. Because the communication configuration remained unchanged, the AC500 controller recognized the replacement panel immediately after downloading the application. The production line resumed normal operation before the scheduled shutdown window expired.
Typical applications include:
- Continuous casting machine operator stations
- Cement kiln process visualization
- Water and wastewater SCADA operator panels
- Material handling and conveyor control
- Food and beverage production lines
- AC500 PLC machine visualization
Transparency SOP: QA & Testing
Every CP676 is inspected and tested before shipment.
- ✔ Verify ABB part number and hardware revision.
- ✔ Inspect the TFT display, touchscreen surface, aluminum housing, and connectors.
- ✔ Perform LCD brightness, pixel, and backlight evaluation.
- ✔ Verify touchscreen calibration over the complete display area.
- ✔ Test Ethernet, serial, USB, and SD card interfaces.
- ✔ Complete extended power-on burn-in testing before ESD-safe packaging.
- CP676
The Veteran’s Tech Trap Guide
⚠️ Back up the HMI project before replacing the hardware.
Many panels installed years ago contain the only working copy of the Panel Builder 600 project. Upload the application from the existing panel whenever possible before removal.
⚠️ Don’t confuse the standard with the -WEB.
Although the hardware platforms are similar, the is intended for PB610 runtime applications, while the is designed for AC500 Web Server visualization. Ordering the wrong version can require rebuilding the operator interface.
PRO TIP:
If the touchscreen appears inaccurate, perform a calibration routine before replacing the panel. Long-term use can gradually shift touch coordinates even though the display and controller remain fully functional.
⚠️ Check the communication settings.
Replacing the HMI without documenting IP addresses, serial parameters, or driver settings can extend commissioning time unnecessarily. Save the complete project and communication configuration before disconnecting the original panel.
Dynamic FAQ
Q1. What is the primary purpose of the ABB ?
The is a 15-inch industrial HMI that provides machine visualization, alarm management, operator interaction, data trending, and recipe management for industrial automation systems.
Q2. Which engineering software is used with the ?
The runs applications created with ABB Panel Builder 600 (PB610) and is commonly integrated into the Automation Builder engineering environment.
Q3. What communication interfaces are available?
The panel includes two 10/100 Mbps Ethernet ports, one configurable RS-232/RS-422/RS-485 serial port, two USB 2.0 Host ports, an SD card slot, and two expansion slots for application flexibility.
Q4. Are New Surplus panels genuine ABB products?
Yes. New Surplus inventory consists of unused original ABB hardware stored under controlled warehouse conditions. Each unit is inspected for display quality, touchscreen operation, communication interfaces, and overall physical condition before shipment.
Q5. Is the compatible with ABB AC500 PLCs?
Yes. The is widely deployed with ABB AC500 PLCs and supports communication with numerous third-party controllers through the drivers available in Panel Builder 600.
Q6. Is warranty available?
Yes. Both New Surplus and professionally refurbished operator panels are supplied with warranty coverage. Warranty duration varies by inventory condition and is confirmed in the quotation.
