Core Product Summary
The Bosch Rexroth / Indramat DM30K1101-D (frequently cross-referenced with manufacturing ID 1070077603-105) is an industrial servo drive and amplifier module engineered for precision motion control applications. Designed to operate within demanding factory automation and machine tool environments, it processes control commands to regulate motor velocity, torque, and positioning.
This drive controller utilizes high-efficiency semiconductor switching topologies to deliver regulated power to matched industrial servomotors. Built into a compact panel-mount enclosure, the unit integrates internal control loop circuitry and dedicated diagnostic and interface connections to maintain stable closed-loop execution across multi-axis manufacturing equipment.
Key Technical Specifications
| Parameter | Specification Details |
| Product Type | Industrial Servo Drive / Amplifier Controller |
| Manufacturer / Brand | Bosch Rexroth / Indramat |
| Model Designation | DM30K1101-D (Manufacturing ID: 1070077603-105) |
| Application Environment | Factory automation, machine tools, and motion control systems |
| Power Topology | High-efficiency semiconductor switching stage |
| Enclosure Rating | IP20 standard industrial control cabinet package |
Detailed Product Overview
The DM30K1101-D functions as a core processing and power-switching node within industrial motion loops. By accepting low-level velocity or position command signals from a centralized programmable logic or motion controller, the unit modulates high-frequency pulse-width modulated (PWM) voltage to drive connected servomotors with high dynamic response.
Designed for robust integration into legacy or specialized automation architectures, the drive incorporates internal protection architecture and feedback loop processing. Its physical layout facilitates secure mounting inside standard electrical control cabinets, ensuring proper alignment with backplane power busses and multi-pin interface cabling.
DM30K1101-D
DM30K1101-D
System Compatibility & Integration Requirements
| Item / Dependency | Verified Compatibility or Requirement | Practical Note |
| Mounting Architecture | Industrial control cabinet panel mounting | Requires upright orientation with unobstructed ventilation paths for thermal dissipation. |
| Control Interface | Dedicated command reference and feedback ports | Interfaced with system-level multi-axis motion controllers or PLCs. |
| Power Distribution | Industrial multi-phase AC mains / DC bus architecture | Requires matching pre-charge and protection circuitry per system design specifications. |
| Motor Integration | Compatible industrial servo motors | Requires proper resolver or encoder feedback cable pairing to ensure loop stability. |
Dimensions, Mounting & Connection Notes
- Enclosure Protection: Rated for IP20 protection; restricted to enclosed, climate-controlled industrial control panels.
- Mounting Style: Backplate panel-mount design requiring vertical orientation to promote optimal convective cooling.
- Terminals: Heavy-duty power connectors and multi-pin signal ports for control input, feedback, and diagnostic data lines.
FAQ
What is the Bosch Rexroth DM30K1101-D?
It is an industrial servo drive controller designed to provide precise power amplification and closed-loop motion control for automated machinery.
What type of environment is this drive built for?
It is engineered for factory automation settings, production lines, and CNC machine tool cells requiring high-dynamic servo response.
How does the DM30K1101-D mount within a system?
It is built as a panel-mount module intended for installation inside standard IP20 industrial electrical control cabinets.
What is the primary role of its switching topology?
The internal semiconductor switching stage regulates power delivery from the DC bus/supply to match precision velocity and torque demands.
