The B&R 5PC910.SX01-00 is a robust, single-slot industrial system unit belonging to the flagship Automation PC 910 series. Functioning as the modular foundation of the APC910 platform, this fanless “Universal Box” chassis is populated with B&R CPU boards, memory modules, and PCI/PCIe expansion cards to create highly customized, real-time industrial computers.
Designed to operate continuously on factory floors without drawing in abrasive dust, the 5PC910.SX01-00 provides native dual Gigabit Ethernet, ultra-fast USB 3.0 interfaces, and Smart Display Link (SDL/DVI) video outputs for HMI visualization. In our field experience, when a legacy APC910 unit experiences backplane or integrated power supply failures, replacing the bare 5PC910.SX01-00 system housing allows you to port over your existing CPU board, storage drives, and expansion cards—restoring the machine to perfect operation without reinstalling the OS or losing proprietary application code.
Key Technical Specifications
| Parameter | Value |
| Part Number | 5PC910.SX01-00 |
| Manufacturer | B&R Automation |
| Product Series | Automation PC 910 |
| Expansion Bus | 1x PCI or 1x PCIe Slot (depends on inserted bus module) |
| Storage Options | 1x CFast Slot, 1x Slide-In SATA III Compact Drive |
| Onboard Network | 2x Gigabit Ethernet (10/100/1000 Mbit/s) |
| Peripheral Ports | 4x USB 3.0, 1x USB 2.0, 1x RS-232 Serial |
| Video Interfaces | 1x SDL / DVI / Monitor, 1x DisplayPort |
| Input Power | 24 VDC ±25% (Max 5.5A) |
| Cooling Method | Passive Heat Sink (Fanless design) |
Application Scenarios & The “Trench” Experience
A large-scale automated warehousing site lost its primary sorting node when a nearby power surge bypassed the cabinet filters, destroying the internal power regulation of the main B&R PC. While the storage drive and Intel CPU module survived, the APC910 chassis would not power on. The original equipment manufacturer (OEM) required a massive integration fee and weeks of lead time for a brand-new generation system.
- High-Speed CNC Control – Servo Synchronization – Houses real-time PCI/PCIe fieldbus cards (like POWERLINK) to govern multi-axis drives.
- Automated Packaging Lines – Central Logic & SCADA – Executes high-speed machine code while feeding remote HMI screens via its SDL port.
- Semiconductor & Cleanroom – Dust-Free Processing – Utilizes its fanless, passive cooling design to prevent airborne particle circulation in sensitive manufacturing areas.
The engineering team stripped the damaged unit, transferred the existing Intel CPU module, RAM, and CFast OS card into a bench-tested 5PC910.SX01-00 replacement system unit. The replacement powered up instantly, booted into the original Windows/Automation Runtime partition, and resumed production flawlessly with all fieldbus addresses unchanged, saving weeks of downtime.
5PC910.SX01-00
5PC910.SX01-00
Transparency SOP: Quality Assurance & Testing
We do not just ship empty housings; we fully populate and test them on live diagnostic benches. Every 5PC910.SX01-00 unit undergoes the following process:
- Inbound Visual & Pin Inspection: Examining all internal backplane connectors, CFast slot pins, and PCI riser headers to ensure zero bent pins or thermal discoloration.
- Backplane Power Verification: Injecting 24VDC and verifying stable internal voltages (+3.3V, +5V, +12V) generated by the system unit’s integrated power supply.
- Live Boot Sequence: Populating the housing with a test CPU board, RAM, and bootable CFast card to confirm POST completion and clean boot into an operating system.
- Interface Stress Test: Looping Gigabit Ethernet packets, writing to USB 3.0, and verifying clean video output on both the DisplayPort and SDL channels.
- Anti-Static Protective Packaging: Disassembling the test components, inserting electrostatic pin covers, and sealing the chassis in ESD-safe packaging within heavy-duty shock foam.
The Veteran’s Tech Trap Guide (Crucial Value-Add)
- ⚠️ CPU and RAM Not Included: The 5PC910.SX01-00 is a “System Unit” (chassis, backplane, and I/O board). It does not include the CPU board, memory, or CFast storage card. You must transfer these components from your existing unit or source them separately.
- ❗ Thermal Interface Material: When transferring your old CPU board into this replacement chassis, you MUST apply fresh thermal paste or ensure the thermal transfer gap pads are intact between the processor and the chassis heat sink. Failing to do so will cause the system to thermally throttle and crash within minutes.
- ⚠️ Match the Bus Unit: The chassis supports either a PCI or PCIe expansion card depending on the specific “bus unit” installed (e.g., 5AC901.BX01-00 vs 5AC901.BX01-01). Ensure you transfer your specific bus riser if you rely on expansion cards.
Frequently Asked Questions (FAQ for Conversion)
Q: Does this chassis have internal cooling fans?
A: No, the standard 5PC910.SX01-00 is completely fanless and utilizes the large external finned heat sink for passive cooling. An active fan kit (optional B&R add-on) can be mounted if your ambient temperatures exceed the passive rating.
Q: Will swapping this housing require software reconfiguration?
A: No. Because your MAC addresses and software licenses are tied to your specific CPU board and CFast/SATA storage drives, transplanting your existing boards into this replacement chassis requires zero software re-engineering.
Q: Can I run a standard desktop monitor off this PC?
A: Yes, it includes a DisplayPort output and an SDL/DVI port, allowing you to connect standard industrial or commercial monitors alongside B&R Automation Panels.
Q: What is the required power supply for this unit?
A: It requires a 24VDC power supply capable of at least 5.5 Amps (depending heavily on what CPU, USB peripherals, and expansion cards you have installed).
Q: What warranty comes with this surplus system unit?
A: Every new surplus and rig-tested 5PC910.SX01-00 system unit comes backed by our full 12-month replacement warranty.
