Description
Product Introduction & Engineering Value
The Rexroth 4WE6Y2-62/EG24N9K4/V is a solenoid-operated directional spool valve from the 4WE6 family. It is designed to switch hydraulic flow between the working ports and thereby control actuator movement. The NG6 configuration makes it a common choice for compact hydraulic control blocks where repeatable directional switching is required.
The complete ordering code matters. The Y2 spool symbol, 62 component series, EG24N9K4 solenoid configuration, and V designation should be matched against the installed valve before substitution. A visually identical 4WE6 valve with a different spool configuration can produce completely different actuator behavior.
Technical Specifications
- Manufacturer: Bosch Rexroth
- Product Family: 4WE6
- Full Order Code: 4WE6Y2-62/EG24N9K4/V
- Valve Type: Direct-operated directional spool valve
- Nominal Size: NG6
- Spool Configuration: Y2
- Actuation: Solenoid
- Solenoid Supply: 24 V DC
- Component Series: 62
- Mounting Standard: ISO 4401 / CETOP 03 interface
- Fluid: Hydraulic oil; exact fluid compatibility must follow the applicable Rexroth specification
- Installation: Manifold/subplate mounting
- Application: Directional control of hydraulic cylinders and hydraulic motors
Ordering-code warning
Do not shorten the part number to 4WE6 when ordering.
For this valve, the spool configuration is especially important. The Y2 designation determines the internal flow path behavior. Replacing it with a different 4WE6 spool symbol may allow the valve to physically mount while changing cylinder motion, pressure behavior, or center-position operation.
Field Application & the “Trench” Experience
A maintenance technician receives a replacement valve after a hydraulic cylinder starts drifting and the original directional valve is suspected. The replacement bolts onto the manifold perfectly. The electrical connector also fits.
The machine still behaves incorrectly.
The problem? The replacement was another 4WE6 valve, but its spool configuration did not match the original. This is a classic hydraulic procurement error: mechanical interchangeability is not functional interchangeability.
For the 4WE6Y2-62/EG24N9K4/V, the full designation should be copied from the original nameplate and compared character by character before the purchase order is released.
Specific application scenarios
- Hydraulic press cylinder control — Switching directional flow during extension, retraction, and neutral states.
- Machine-tool hydraulic clamping — Controlling hydraulic actuator direction while maintaining the specified center condition.
- Material-handling hydraulic power unit — Controlling cylinders or compact hydraulic actuators from a PLC-driven solenoid output.
Transparency SOP: QA & Testing
For new-surplus or refurbished hydraulic valves, testing should cover both the electrical solenoid and the hydraulic switching function.
- Part-number inspection — Confirm 4WE6Y2-62/EG24N9K4/V on the actual valve.
- Visual inspection — Check the valve body, mounting face, threaded ports, seals, solenoid housing, connector, and nameplate.
- Electrical test — Verify solenoid coil resistance and inspect the electrical connector for damage.
- Spool test — Confirm that the spool shifts correctly when the solenoid is energized.
- Hydraulic test — Apply an appropriate test pressure and verify the correct port-to-port flow paths.
- Leak test — Check external sealing and internal leakage under controlled conditions.
- Final inspection — Record valve identification, coil voltage, test pressure, leakage results, and condition.
For refurbished stock, the seller should be able to state whether the valve was merely cleaned and inspected or actually disassembled, resealed, and hydraulically tested.
4WE6Y2-62/EG24N9K4/V
4WE6Y2-62/EG24N9K4/V
The Veteran’s Tech Trap Guide
⚠️ Trap #1 — Buying by “4WE6” alone.
This is the fastest way to get the wrong valve. The 4WE6 family contains many spool, actuation, voltage, and configuration variants.
PRO TIP: Treat the entire 4WE6Y2-62/EG24N9K4/V string as the purchasing identifier.
⚠️ Trap #2 — Ignoring the Y2 spool code.
The spool symbol determines how the hydraulic ports communicate in the valve’s operating positions. If the machine depends on a particular center condition, substituting another spool can cause unexpected actuator movement.
⚠️ Trap #3 — Assuming 24 V means 24 V DC.
The complete solenoid designation must be checked. Do not assume the electrical characteristics from a partial model number or from the machine’s nominal control voltage.
⚠️ Trap #4 — Contaminating the hydraulic system during replacement.
A new valve does not compensate for dirty hydraulic oil. Keep the manifold and valve ports clean, replace seals where required, and prevent contamination from entering open hydraulic lines.
Dynamic FAQ
What is Rexroth 4WE6Y2-62/EG24N9K4/V?
It is a 4WE6-series, NG6, solenoid-operated directional spool valve used to control hydraulic flow to actuators. The specified configuration uses a Y2 spool and 24 V DC solenoid arrangement.
Is the 4WE6Y2-62/EG24N9K4/V a 4/3-way valve?
The 4WE6 designation represents the four-port, three-position directional valve family. The exact center-position flow behavior is determined by the specified spool configuration, so the hydraulic schematic should be checked before installation.
Can another 4WE6 valve replace it?
Not without verification. The replacement must match the spool configuration, solenoid voltage, connector/electrical arrangement, mounting interface, and hydraulic application.
What should I verify before ordering?
Check the actual valve marking:
4WE6Y2 → 62 → EG24N9K4 → V
Also confirm the nameplate, solenoid voltage, connector, mounting dimensions, hydraulic schematic, and existing machine valve configuration.
Is new-surplus stock suitable for a critical hydraulic system?
It can be, provided the valve is unused and properly stored and the seller can provide appropriate inspection or functional-test evidence. Check seals carefully because long storage can affect elastomer condition.
What warranty should I expect?
Warranty is supplier-specific. For production equipment, obtain written confirmation of the warranty period, testing performed, return conditions, and whether the warranty covers functional failure after installation.
