Description
Core Product Summary
The SAM / SAM4S EMP-2200M is a heavy-duty, direct thermal receipt and transaction printer designed for point-of-sale (POS), hospitality, and industrial kiosk applications. Built for high-throughput printing, the unit produces sharp, clear text, barcodes, and logos on standard thermal paper rolls without requiring ink or ribbon consumables.
Engineered for straightforward integration into retail management platforms, medical devices, or embedded industrial equipment, the EMP-2200M features versatile physical interface options (including RS-232 serial and parallel ports). Its compact footprint, combined with an integrated auto-cutter mechanism and drop-in paper loading system, delivers consistent performance in space-constrained operational environments.
Key Technical Specifications
| Technical Parameter | Specification Detail |
| Brand / Manufacturer | SAM4S / SAM |
| Model Number | EMP-2200M |
| Print Technology | Direct thermal printing |
| Media / Paper Width | 80 mm (standard thermal paper) |
| Print Resolution | 203 dpi (8 dots/mm) |
| Interface Ports | RS-232 Serial (DB9/DB25), Parallel (IEEE 1284 / Centronics) |
| Cutting Mechanism | Integrated auto-cutter (Full or Partial cut) |
| Command Emulation | ESC/POS command set compatible |
| Power Supply Input | 24 VDC external power adapter |
| Barcode Support | 1D barcode sets (UPC-A/E, Code 39, Code 128, EAN-8/13, ITF) |
| Mounting Options | Desktop / Countertop, Panel-mount / Embedded option |
Engineering Selection Highlights
- Direct Thermal Printing Mechanism: Eliminates the need for ribbons, ribbons cartridges, or ink rollers, lowering consumable costs and routine maintenance requirements.
- Industry-Standard Command Emulation: Compatible with the ESC/POS command language, allowing immediate integration into legacy retail, ticketing, and industrial printing software layers.
- Flexible Dual-Interface Support: Provides physical serial (RS-232) and parallel connections to communicate directly with older POS terminals, industrial automation controllers, or PC platforms.
- Rugged Internal Auto-Cutter: Factory-fitted auto-cutter handles high-volume receipt and ticket separation with options for full or partial cuts.
- Drop-In Media Loading: Simplifies paper roll replacement for operators, minimizing downtime in busy transaction or customer-facing environments.
System Compatibility & Integration Requirements
| Item / Dependency | Verified Compatibility or Requirement | Practical Note |
| Command Emulation | ESC/POS protocol supported | Ensures compatibility with standard receipt and ticket layout software. |
| Host Interfaces | RS-232 Serial or Parallel | Baud rate and parity settings must match the host controller configuration. |
| Power Supply | 24 VDC regulated power adapter | Requires a dedicated 24V power supply module with matching pin polarities. |
| Cash Drawer Kick-Out | Integrated RJ11 cash drawer port | Allows automatic opening of standard 24V cash drawers upon receipt printing. |
EMP-2200M
Dimensions, Mounting & Connection Notes
- Form Factor: Compact desktop profile suitable for point-of-sale counters, service desks, or embedded equipment enclosures.
- Cable Connections: Rear-panel interface layout provides distinct ports for power input, host communication cable (Serial/Parallel), and RJ11 cash drawer line.
- Media Capacity: Accommodates standard 80 mm thermal paper rolls with an outer diameter up to 80 mm.
- Maintenance Access: Top cover unlatches via a mechanical release button for rapid access to the print head and paper path.
Detailed Product Overview
The SAM4S / SAM EMP-2200M is a durable direct thermal printer designed for applications requiring consistent receipt generation under steady daily use. Featuring a 203 dpi resolution print head, the unit produces clean, high-contrast text, custom graphic logos, and machine-readable 1D barcodes on standard 80 mm thermal paper stock.
The printer incorporates an internal auto-cutter and an intuitive drop-and-print paper path that minimizes user intervention during media swaps. Operating on standard 24 VDC power, the unit integrates smoothly into both new system designs and retrofitted infrastructure via serial (RS-232) or parallel interface ports. Full ESC/POS command compatibility simplifies firmware configuration and software driver setup, making the EMP-2200M an effective hardware choice for retail, hospitality, and embedded printing applications.
Applications & System Role
The SAM EMP-2200M functions as a dedicated hardcopy output device within point-of-sale networks, commercial ticketing booths, and industrial data logging stations. It receives print commands and raster data from a host terminal, formatting the input into receipts, order tickets, or diagnostic logs in real time. Common deployments include kitchen display and printing stations, retail checkout lanes, parking garage ticket dispensers, and industrial panel-mount logging stations.
FAQ
What print technology does the SAM EMP-2200M use?
The EMP-2200M uses direct thermal printing, requiring thermal-sensitive paper and no ink ribbons or toner.
What media size is compatible with the EMP-2200M?
It accepts standard 80 mm wide direct thermal paper rolls.
What host interfaces are built into the printer?
The printer features serial (RS-232) and parallel interface ports for connecting to host computers or POS terminals.
Is the SAM EMP-2200M equipped with an automatic cutter?
Yes, it includes an integrated heavy-duty auto-cutter supporting full or partial cuts.
What command set language does the unit support?
It supports the standard ESC/POS command emulation set for straightforward software driver setup.
