Not every communication problem originates from the controller. In long-running ABB process automation systems, the fieldbus interface is frequently the component that determines whether remote I/O remains visible to the control network. The ABB CI810B provides the AF100 communication bridge between the S800 I/O system and higher-level ABB controllers.
Designed for AC 800M and System 800xA architectures using the AF100 network, the CI810B enables deterministic communication with distributed I/O while preserving existing plant infrastructure. For facilities extending the service life of legacy AF100 installations, replacing the communication interface is often considerably less disruptive than migrating to a different fieldbus.
Technical Specifications
| Parameter | Specification |
|---|---|
| Manufacturer | ABB |
| Model | CI810B |
| Article Number | 3BSE020520R1 |
| Product Type | AF100 Fieldbus Communication Interface |
| Communication Network | Advant Fieldbus 100 (AF100) |
| Physical Interface | Two AF100 Twisted-Pair Modems |
| Communication Speed | 1.5 Mbit/s |
| Compatible Systems | ABB S800 I/O, AC 800M, System 800xA |
| ModuleBus Connection | Supported |
| Included Accessories | Power Supply Connector, TB807 ModuleBus Terminator, Terminal Blocks, Connector |
| System Software | Basic System Software Version 1.5 Preloaded |
| Product Weight | Approximately 0.5 kg |
Field Application & The “Trench” Experience
During a scheduled shutdown at a wastewater treatment facility, operators experienced intermittent loss of several remote S800 I/O stations connected through the network. Cable insulation tests and controller diagnostics showed no permanent wiring faults, yet communication continued to drop under load.
The maintenance team replaced the aging CI810B communication interface while leaving the controller program and field wiring unchanged. After restoring power, the network stabilized immediately, and the remote I/O stations returned to normal operation without additional configuration.
Typical applications include:
- Distributed S800 I/O networks in municipal water treatment plants
- Boiler control systems using AC 800M controllers
- Pulp and paper process automation with fieldbus communication
- CI810B
- CI810B
Transparency SOP: QA & Testing
Every module is processed through a documented inspection workflow before shipment.
- ✔ Verify ABB article number 3BSE020520R1
- ✔ Inspect PCB, connectors, and housing for physical damage
- ✔ Verify ModuleBus and connector integrity
- ✔ Perform power-up verification using compatible ABB hardware
- ✔ Confirm communication diagnostics and status indicators
- ✔ Package using anti-static protection and impact-resistant materials
Professionally refurbished modules also undergo functional communication testing before release.
The Veteran’s Tech Trap Guide
⚠️ is not PROFIBUS.
The is dedicated to Advant Fieldbus 100. Although several ABB communication modules share a similar appearance, they support entirely different fieldbus protocols. Verify the network architecture before ordering.
⚠️ Check the accessories before replacing the module.
The communication interface depends on the correct TB807 ModuleBus Terminator and associated connectors. Missing or damaged accessories can create intermittent communication faults that resemble module failures.
PRO TIP:
Before removing the existing , document the node configuration and inspect the twisted-pair cable shield termination. In older installations, degraded cable terminations are often responsible for unstable communication rather than the interface itself.
⚠️ Don’t ignore software revisions.
When replacing hardware in legacy System 800xA or AC 800M installations, verify that the controller software revision supports the installed communication interface to avoid unnecessary commissioning delays.
