Description
3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Part Number | 3BHB007211R117 |
| Module Type | Control Card |
| Application | UNITROL excitation control systems |
| Function | Isolated analog input and control processing |
| Operating Temperature | -20°C to +70°C (typical) |
| Weight | Approx. 1.08 kg |
| Mounting | Internal to excitation cabinet |
| Reliability | Designed for continuous industrial operation |
4. Product Introduction
The ABB XVC768117 (3BHB007211R117) is a control card used in ABB UNITROL excitation systems. It handles key control tasks including isolated analog inputs for reliable generator voltage regulation.
This card supports stable operation in power generation applications. Field teams use it for its integration with existing excitation platforms and dependable performance under varying load conditions.
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No analog input readings | Power or wiring fault | ✅ High | Measure input signals at terminals | Verify field wiring and supply voltage |
| Control instability | Parameter or board issue | ✅ High | Check excitation diagnostics | Review parameters and logs |
| Communication failure | Bus or card fault | ✅ Medium | Inspect status indicators | Test connections to master controller |
| Overheating | Poor ventilation | ✅ Medium | Monitor cabinet temperature | Ensure adequate cooling airflow |
| Intermittent faults | Loose connectors | ✅ High | Visual and mechanical inspection | Reseat card and tighten connections |
Provide system logs and photos of the installation for support cases.
- XVC768117 3BHB007211R117
- XVC768117 3BHB007211R117
6. Frequently Asked Questions (FAQ)
Can the XVC768117 be hot-swapped? No. Shut down the excitation system and follow safety protocols. Live work on excitation controls can damage equipment or create hazards.
What systems use this control card? It is primarily used in ABB UNITROL 5000 and related excitation control systems for synchronous machines.
Is this New Original stock? Yes. New Original / New Surplus with full traceability. Cards are tested for basic functionality prior to shipment.
Will it serve as a direct replacement? Yes in matching configurations. Document existing settings and connections before swapping.
How do I commission or test it? Use ABB excitation commissioning tools. Perform input/output checks and system tuning per the UNITROL manual.
What is the warranty? 1-year warranty from shipment on New Original units for defects under standard operating conditions.
Why source surplus? Immediate stock availability compared to factory production. All cards undergo inbound visual and electrical inspection. Test reports available upon request.
