B&R 5PC910.SX02-00 Automation PC 910 Industrial Computer

Description

Product Introduction & Engineering Value

The B&R 5PC910.SX02-00 APC910 system unit is built for automation applications requiring industrial computing power, flexible expansion, and long-term machine integration. It provides the mechanical and electrical platform for APC910 CPU boards, PCI/PCIe bus units, storage devices, and industrial communication options.

For engineers maintaining mature B&R-controlled equipment, the APC910 is more than an industrial computer chassis. Its expansion layout, storage architecture, firmware environment, and controller interfaces are often tied directly to the machine design. A correctly matched 5PC910.SX02-00 replacement can restore an existing system without unnecessary software migration or cabinet redesign.

Technical Specifications

Field Application & The “Trench” Experience

A metal processing plant operating an automated cutting system experienced repeated controller interruptions after several years of continuous operation. The machine PLC logic remained functional, but visualization, production data logging, and operator diagnostics became unavailable.

The maintenance team initially focused on network communication because several alarms appeared during the failure event. After isolating the system, engineers identified the APC910 industrial PC hardware as the source of instability.

A replacement B&R 5PC910.SX02-00 system unit was installed with the existing CPU board, PCI communication hardware, and CFast storage transferred from the original machine. After verification of Automation Runtime operation, the production cell returned to service.

The key field lesson: industrial PC hardware failures often appear as software or network problems because the PC sits between multiple automation layers.

Typical application scenarios:

• B&R Automation Runtime machine controllers
• High-speed packaging equipment with integrated visualization
• CNC production systems using PCI communication cards
• Assembly lines requiring industrial PC-based data processing

5PC910.SX02-00

5PC910.SX02-00

Transparency SOP: QA & Testing

A replacement APC910 system unit requires hardware-level validation before deployment.

Inspection workflow:

1. Identification Check

• Verify B&R label.
• Confirm exact model: 5PC910.SX02-00.
• Check housing condition and revision markings.

2. Power Verification

• Apply 24 VDC input.
• Confirm startup sequence.
• Check status LEDs:
  • Power
  • HDD
  • Link
  • Run

3. Interface Testing

• Test Ethernet communication.
• Verify RS232 operation.
• Check USB ports.
• Confirm display output.

4. Expansion Validation

• Inspect PCI/PCIe slots.
• Verify bus unit compatibility.
• Test communication cards when installed.

5. Storage and Controller Testing

• Verify CFast access.
• Confirm BIOS operation.
• Check MTCX controller functions.
• Validate retained data support.

6. Final Documentation

• Record hardware configuration.
• Save test results.
• Assign inventory condition:
  • New Surplus
  • Refurbished
  • Tested Used

The Veteran’s Tech Trap Guide

⚠️ Trap #1: Buying the System Unit Without Checking the Bus Configuration

The 5PC910.SX02-00 is only the system unit. The final expansion capability depends on the installed APC910 bus unit.

Verify:

• 2 PCI slots
• PCI + PCIe combination
• 2 PCIe slots

PRO TIP: Existing fieldbus cards are often the hidden dependency during replacement projects.

⚠️ Trap #2: Ignoring the CFast Storage Image

The hardware may power up correctly but still fail to run the machine.

Before replacement:

• Clone the CFast card
• Backup Automation Studio project
• Record operating system version
• Save licenses and configuration files

⚠️ Trap #3: Assuming CPU Boards Are Included

The 5PC910.SX02-00 is a system chassis/platform. CPU boards are separate components.

Supported CPU options include multiple Intel processor-based APC910 CPU boards.

Always verify:

• CPU model
• RAM capacity
• Operating system requirements
• Application workload

Dynamic FAQ

Q1. What is the B&R 5PC910.SX02-00 used for?

The B&R 5PC910.SX02-00 is an Automation PC 910 system unit used for industrial computing tasks including machine control, visualization, communication, and automation applications.

Q2. Does the 5PC910.SX02-00 include a CPU board?

No. The unit is a system platform. A compatible APC910 CPU board must be installed separately according to application requirements.

Q3. What expansion options are available with the 5PC910.SX02-00?

The APC910 system supports two-slot expansion configurations, including PCI, PCIe, and mixed PCI/PCIe arrangements depending on the installed bus unit.

Q4. Can the 5PC910.SX02-00 replace an older APC620 or APC810 system?

Not automatically. Engineers must verify:

• Mechanical dimensions
• Software compatibility
• CPU performance requirements
• Expansion cards
• Storage image
• Machine application environment

Q5. What should buyers verify before purchasing a New Surplus 5PC910.SX02-00?

Recommended checks:

• Correct B&R part number
• Housing condition
• Bus unit compatibility
• PCI/PCIe slot condition
• Power supply testing
• Warranty documentation

Q6. Is refurbished 5PC910.SX02-00 suitable for critical automation systems?

Yes, when the unit has passed power, communication, expansion, and controller verification tests. For APC910-based machines, tested replacement system units are commonly maintained as strategic spare inventory.
