EATON XVS-460-57MPI-1-10 139970 UR38508 5.7-Inch HMI Touch Panel Display

Description

Product Introduction

The Eaton XVS-460-57MPI-1-10 (Article No. 139970, often cross-referenced as UR38508) is a heavy-duty, compact 5.7-inch industrial HMI panel PC designed for high-density visualization and direct machine control. Unlike standard 5.7″ panels that top out at low QVGA resolution, the XVS-460 features a full VGA (640×480) high-contrast TFT color display, rendering crisp graphics, detailed trend lines, and dense alarm tables in a small footprint.

Built on Eaton’s XVS400 platform, this unit features an onboard Siemens MPI / PROFIBUS DP interface that plugs directly into Siemens S7-300, S7-400, and compatible PLC networks without external protocol convertors. Protected by a rugged metal chassis, stainless steel front bezel, and an IP65 front face, it delivers reliable, fanless execution of Galileo HMI screens and XSoft-CoDeSys soft-PLC logic in high-vibration and harsh factory environments.

Key Technical Specifications

Application Scenarios & The “Trench” Experience

Picture this: It’s 2:45 AM on a weekend production run at a high-volume precision assembly facility. A key 5.7″ operator touch panel connected via an MPI network to a Siemens S7-300 PLC suffers a severe backlight failure and touch response loss. The cell is stuck, holding up an entire downstream packing line. Standard replacement 5.7″ panels with QVGA (320×240) resolution fail to display the application properly because the original Galileo HMI project was compiled specifically for VGA (640×480). Unboxing a pre-tested XVS-460-57MPI-1-10 (139970 / UR38508), inserting the CompactFlash card holding the runtime files, and plugging in the Sub-D9 MPI connector restores full resolution, clean graphical alignment, and normal production in under 20 minutes.

• High-Density Machine Consoles – Ideal for compact machine operator panels that require sharp text, high-resolution gauge graphics, and detailed fault diagnostics without taking up large enclosure cutouts.
• Siemens S7 Network Infrastructure – Connects directly to S7-300 / S7-400 PLCs over MPI (187.5 kbit/s) or high-speed PROFIBUS DP (up to 12 Mbit/s) bus segments.
• Washdown & Severe Industrial Skids – Mounted on stainless steel control boxes where the IP65-rated front face withstands washdown spray, oil mist, and dust accumulation.

Transparency SOP: Quality Assurance & Testing

Every unit undergoes a multi-point bench audit before shipping:

1. Housing & Bezel Inspection: Physical evaluation of the stainless steel bezel, glass touch panel substrate, rear terminal connectors, and continuous perimeter sealing gasket.
2. 24V DC Power Sweep Test: Powered on a precision DC bench supply and swept between 19.2V and 30.0V DC to verify internal voltage regulator stability, backlight illumination, and clean OS boot cycles.
3. Resistive Touch Calibration Matrix: Full-surface touch grid test verifying 100% responsiveness and accuracy across all quadrants to eliminate coordinate drift or dead zones.
4. MPI / PROFIBUS DP Port Verification: Communication stress test using a Siemens S7 test rack, confirming error-free data exchange from 187.5 kbit/s up to 12 Mbit/s.
5. Anti-Static Cleaning & ESD Packaging: Neutralized against static discharge, vacuum-sealed in anti-static ESD bags with fresh desiccant, and packaged in high-impact custom foam.

XVS-460-57MPI-1-10 139970 UR38508

XVS-460-57MPI-1-10 139970 UR38508

The Veteran’s Tech Trap Guide (Crucial Value-Add)

• ⚠️ Do Not Confuse XVS-460 (VGA) with XVS-440 (QVGA)!

  The 460 in XVS-460-57MPI-1-10 indicates a VGA (640×480) resolution 5.7″ screen. The 440 series uses a QVGA (320×240) resolution screen. Installing an XVS-440 panel where an XVS-460 was originally used will cause Galileo runtime screens to clip, truncate, or fail to display correctly due to the lower pixel density.

• ❗ Verify “UR38508” Cross-Reference Part Number

  UR38508 is a common OEM cross-reference, internal catalog, or drawing index number for Eaton Article No. 139970. When substituting parts during maintenance, verify that both the model code (-57MPI-1-10) and article number match to ensure full hardware equivalence.

• ⚠️ Check Bus Termination Resistors on the MPI Cable

  When attaching the 9-pin Sub-D cable to the onboard MPI/PROFIBUS port, ensure the termination switch on the connector block is set properly. If the is the last device on the MPI segment, set the termination switch to ON to prevent noise reflection on the communication line.

• ❗ Use Industrial CompactFlash Cards for System Memory

  OS images, Galileo visualization projects, and soft-PLC logic are stored on a removable CompactFlash (CF) card. Always use an industrial-grade Type I CF card formatted to FAT16/FAT32 (maximum 2 GB recommended for legacy Windows CE stability). Commercial retail cards frequently corrupt during power interruptions.

Frequently Asked Questions (FAQ for Conversion)

Q: What is the difference between model number -57MPI-1-10, article number 139970, and reference UR38508?

A: They refer to the exact same physical product. is the functional model code detailing the 5.7″ size, VGA resolution, and MPI interface. 139970 is Eaton’s official 6-digit ordering/article number, and is an OEM/vendor cross-reference number for the unit.

Q: Can this 5.7″ display communicate directly with a Siemens S7 PLC?

A: Yes. The onboard MPI/PROFIBUS DP interface supports direct connection to Siemens S7-300, S7-400, and compatible controllers without needing external network gateways or protocol convertors.

Q: Which software applications are used to program this terminal?

A: Visualization screens are created using Eaton’s Galileo software. If the integrated soft-PLC execution engine is enabled, logic programming is handled via XSoft-CoDeSys-2 or XSoft-CoDeSys-3.

Q: Is the touch screen operated via resistive or capacitive touch?

A: This model features a durable 4-wire analog resistive touch screen (glass substrate with a protective film overlay), making it suitable for operation with bare fingers, industrial work gloves, or a plastic stylus.
