GESPAC GESVIG-4W | Composite Video Graphics Board

Description

Core Product Summary

The GESPAC GESVIG-4W is a composite video graphics board designed for video and graphics processing within GESPAC modular industrial computer and control systems. It belongs to the VIG-4W graphics board family and serves as the display-side interface in legacy GESPAC architectures, distinct from CPU, memory, or I/O modules. The board is a plug-in PCB, and its compatibility depends on the host GESPAC chassis, backplane, board revision, and connector arrangement.

Because public documentation for this board is limited, the most reliable identification attributes are its functional designation (VIG-4W) and its role as a video graphics controller. Variants such as GESVIG-4W/9340 have been documented, so procurement should compare the complete board label and revision markings rather than relying on the base model number alone.

Key Technical Specifications

Detailed Product Overview

The GESVIG-4W operates in the visualization path of a GESPAC control system, handling the graphics and video signals that a host workstation or control display requires. In a modular architecture that also includes CPU, memory, serial I/O, digital I/O, analog input, backplane, and power-distribution boards, the GESVIG-4W is specifically responsible for the display interface rather than for computation or field I/O. This functional distinction matters during replacement or spare-parts sourcing: a board that powers up may still be incompatible if its video output characteristics or connector arrangement do not match the host system’s expectations.

Publicly accessible component records consistently identify the GESVIG-4W as a video graphics controller or composite video graphics board. Some unrelated reseller listings have classified the name under power modules or signal conditioners, but those descriptions conflict with the better-supported identification and should not be used for engineering decisions. The board also appears in repair documentation under the shorter VIG-4W designation and the reference GESVIG-4W 9736 / VIG-4W, which is useful when tracing obsolete inventory or matching maintenance records that use alternate naming conventions.

Because detailed parameters such as video resolution, refresh rate, connector pinout, memory size, bus interface, power consumption, and supported monitor lists are not consistently documented across public sources for every revision, replacement planning should rely on the physical board markings and the host-system documentation. The board’s role in the system is clear, but its exact integration boundaries are revision- and host-dependent.

GESVIG-4W

GESVIG-4W

System Compatibility & Integration Requirements

Engineering Selection Highlights

• The board’s verified function is video graphics processing, not general-purpose I/O or power conversion. Confirm that the intended application is the display interface of a GESPAC system before selecting this board.
• VIG-4W is a documented functional designation for the same board. Maintenance records or procurement lists may use VIG-4W or GESVIG-4W interchangeably, so search under both identifiers.
• Documented variants include GESVIG-4W/9340 and VIG-4W 9340. The complete board label and revision markings should be compared, not just the base model number.
• Compatibility depends on the host GESPAC chassis, backplane, and connector arrangement. Physical fit alone does not confirm that the video interface will match the system’s display path.
• Publicly available detailed specifications are limited. Resolution, interface type, and power requirements should be confirmed from the physical board and host-system records before a replacement is specified.

FAQ

What is the GESPAC GESVIG-4W?
The GESVIG-4W is a composite video graphics board manufactured by GESPAC for video and graphics processing in modular industrial computer and control systems.

Is the GESVIG-4W the same as the VIG-4W?
VIG-4W is a documented functional designation associated with the GESVIG-4W. Repair records and parts catalogs may use either name.

Which GESPAC systems use the GESVIG-4W?
The board belongs to the GESPAC modular industrial control system family, where it occupies the display-side graphics role alongside CPU, memory, and I/O boards.

What should I check before replacing a GESVIG-4W?
Record the complete board label, revision, serial number, and PCB markings from the installed unit, and verify the host chassis, backplane, and connector arrangement.

Does the GESVIG-4W have published video resolution or interface specifications?
Publicly available documentation does not consistently state resolution, refresh rate, or connector pinout for every revision. These details should be confirmed from the physical board and the host-system documentation.

Verification & Troubleshooting Notes

When diagnosing an identification or integration issue with a GESPAC GESVIG-4W, begin with the physical board markings. Record the full part number, the VIG-4W designation if present, any variant suffix such as 9340, the serial number, and all PCB markings before removal. Compare these against the replacement candidate, because boards that share the base GESVIG-4W name may differ in revision-level details that affect display compatibility.

If the system does not recognize the board or the display path does not function after installation, distinguish between a physical fit problem and a video-interface mismatch. Confirm that the board is seated in the correct chassis position and that the backplane connector arrangement matches the host documentation. Do not assume that a board which powers up is automatically compatible with the host’s expected video timing or connector pinout; those parameters must be verified from the system records rather than inferred from the model name alone.
