The IS200TBCIH2BCE is a contact input terminal board from GE’s Mark VIe turbine control platform. It serves as the field wiring interface for discrete contact signals in gas and steam turbine control systems, connecting directly to the VBCI or similar processor boards.
In our field experience, this board stands out for its robust group isolation and straightforward screw terminal design. It handles the noisy environments of power plants better than basic I/O cards, giving you clean signal conditioning without extra hardware layers in most Mark VIe architectures.
Key Technical Specifications
| Parameter | Value |
|---|---|
| Contact Inputs | 24 dry contacts |
| Isolation | Group isolated |
| Voltage Rating | 24 VDC nominal |
| Power Consumption | Approx. 20.6 W (terminal board) |
| Dimensions | 13.0″ H x 4.0″ W (approx.) |
| Operating Temp | -30°C to +65°C |
| Functional Acronym | TBIC |
| Mounting | DIN rail or chassis |
| Series Compatibility | Mark VIe |
| Connectors | Barrier-style screw terminals |
Application Scenarios & The “Trench” Experience
Nothing kills a shift faster than a turbine trip at 3 AM because a contact input board finally gave up after twenty years of vibration and thermal cycling. We’ve all been there — DCS alarms flooding in while you’re racing to the control room.
- Power Generation – Gas turbine Mark VIe controls – Required for reliable flame detector and limit switch monitoring where false trips cost thousands per minute.
- Oil & Gas – Compressor control panels – Handles critical shutdown contacts in hazardous areas with solid isolation.
- Process Industries – Boiler auxiliary systems – Interfaces valve position and pump status contacts in high-noise electrical environments.
- Marine – Propulsion turbine controls – Compact form factor fits tight cabinets on offshore platforms.
Last year we swapped one of these into a 7FA turbine that had been down for six hours. The old board’s isolation finally leaked enough to cause intermittent faults. Thirty minutes after installing the replacement, the unit was back online. Downtime like that hurts the soul — and the bonus check.
- IS200TBCIH2BCE
- IS200TBCIH2BCE
Transparency SOP: Quality Assurance & Testing
We don’t just ship boxes; we test them on actual Mark VIe racks.
- Inbound Inspection (verify OEM seals, check for counterfeit markings, physical damage).
- Live Rig Testing (full power-up, contact simulation on all 24 channels, communication handshakes with VBCI processor).
- Electrical Parameter Checks (isolation resistance testing between groups).
- Firmware/Revision Verification (confirm revision level matches expected Mark VIe compatibility).
- Final QC & Anti-static Packaging (double-bagged, foam in place, labeled with test data).
The Veteran’s Tech Trap Guide
⚠️ DIP switch and jumper settings matter. Take a clear photo of the old board’s configuration before you pull it. One wrong jumper and your contact inputs read backwards or stay stuck.
❗ Backplane connector alignment. These boards slide into the VME-style rack. Misalign the guide pins and you’ll bend contacts. Go slow on the last inch.
⚠️ Firmware/processor compatibility. The H2BCE revision works with current Mark VIe controllers, but verify your VBCI or equivalent board firmware supports it. Mismatch causes weird I/O faults that waste hours.
One thing to watch out for is grounding. Make sure the cabinet ground strap is solid. Poor grounding turns clean contact signals into noise that drives the historian crazy.
Frequently Asked Questions
Is the IS200TBCIH2BCE hot-swappable? No. Power down the associated I/O pack before swapping. Pulling it live risks backplane damage and processor faults.
Will this work as a direct replacement for IS200TBCIH2B? Yes in most cases. The BCE revision includes minor updates for improved reliability. Confirm your system firmware and cabinet drawings.
What’s the warranty? 12 months from shipment on all tested surplus units. We stand behind the testing.
Why is this cheaper than buying direct from GE? We source new surplus and refurbished stock from decommissioned or upgraded plants. Same OEM quality, no OEM markup or 26-week lead time.
Do you test every board? Every single one. We simulate real contact inputs and verify isolation on a live Mark VIe rack before it ships.
Is this a genuine GE part or refurbished? Genuine GE. Most units are new surplus (factory sealed or lightly used in OEM spares). Full traceability on request.
How do I handle the terminal wiring during swap? Label every wire or use the old board as a template. The screw terminals are straightforward but time-consuming if you mix them up.
