MAN MM2-4TX1 Fast Ethernet Media Converter Module

Description

Product Introduction

The Hirschmann MAN MM2-4TX1 is a Fast Ethernet media module designed for the MICE (Modular Industrial Ethernet) switch family, including base switch units like the MS20 and MS30. It adds four shielding-protected RJ45 copper ports to modular industrial backplanes, enabling targeted network expansion in harsh control cabinets without replacing the core switch unit.

Engineered specifically for heavy industrial environments, the MM2-4TX1 offloads local copper drop connections from central fiber runs. Unlike fixed-port managed switches that force full panel redesigns when port counts grow, this module slides directly into open slots on MS-series bases. It gives field networks flexible copper density right where field devices converge.

Key Technical Specifications

Application Scenarios & The “Trench” Experience

Picture this: It’s 2:15 AM on a Sunday. A manufacturing line trips out because an intermittent Ethernet link on a sub-panel drops connection to three drive cabinets. The link LED on port 3 of a legacy MICE expansion block is completely dead—corroded pins from years of harsh industrial vibration and ambient sulfur. Pulling the whole managed switch means losing network architecture settings and risking extended downtime. Swapping just the failing 4-port copper expansion module gets the line back up before the morning shift arrives.

• Automotive Assembly Lines – Local Control Cabinets – Connects multiple PLC remote I/O drops and HMI panels back to a central MS30 backplane over shielded copper drops.
• Water/Waste Treatment – Pumping Sub-stations – Provides local panel connectivity for motor starter controllers and flow meters tied into a central optical ring.
• Power & Utility Sub-stations – Relay Control Panels – Supplies localized high-noise immunity copper connections to protection relays inside isolated control racks.

Field Case Study

A paper mill in Oregon suffered a lightning surge that spiked through an ungrounded Ethernet drop, destroying four RJ45 ports on an active MS20 switch bank. Sourcing an entire replacement switch would have required a 6-week lead time and hours of re-configuring VLANs and ring redundancy setups. Instead, technicians pulled the blown MAN MM2-4TX1 card, slid in a fresh surplus module, and restored link handshakes within 8 minutes—saving an estimated $42,000 in lost production time.

MM2-4TX1

Transparency SOP: Quality Assurance & Testing

We test every Hirschmann module before it leaves our shop. We don’t just inspect the housing; we build active bench setups.

1. Inbound Inspection: Verification of genuine Hirschmann casing, serial tag integrity, backplane connector pin alignment, and PCB corrosion checks.
2. Live Rig Testing: Insertion into a live Hirschmann MS20/MS30 base frame to confirm backplane detection, auto-negotiation, and backplane bus recognition.
3. Traffic Load Testing: Running sustained bi-directional Fast Ethernet throughput tests across all 4 RJ45 ports using automated packet analyzers to verify zero packet loss.
4. Firmware & Diagnostics Check: Checking module reporting status via the base unit’s CLI and web management console to confirm clean port status metrics.
5. ESD Protection: Final cleanup with electronic contact cleaner, followed by sealing in anti-static ESD shielding bags prior to custom foam packaging.

The Veteran’s Tech Trap Guide (Crucial Value-Add)

• ⚠️ Backplane Pin Alignment: Don’t force the module into the MS base frame. The multi-pin connector on the rear can bend if inserted at an angle. Slide it smoothly along the guide rails until it seats firmly before tightening the retaining screws.
• ❗ Hot-Swapping Caveats: While MICE base units support hot-swapping modules, popping a module under heavy load can trigger temporary topology change notifications in Hiper-Ring setups. Mechanically lock your ring pathways or mute network alarms first if you must service it live.
• ⚠️ Cable Shielding Matters: Industrial electrical noise will murder Fast Ethernet drops. Always use STP (Shielded Twisted Pair) Cat5e or Cat6 cables and ensure the RJ45 metal shielding tabs on the MM2-4TX1 make tight contact with your cable boots.
• ❗ DIP Switch & Base Capabilities: Make sure your MS20/MS30 base backplane has sufficient power budgets allocated if you are mixing media modules with high-draw PoE or fiber units on the same frame.

Frequently Asked Questions (FAQ for Conversion)

Q: Is the MAN MM2-4TX1 hot-swappable in an active MS20/MS30 base frame?

A: Yes, the MICE modular architecture supports hot-swapping. However, any active Ethernet connections on those 4 ports will drop immediately upon removal.

Q: Does this module require software configuration or IP assignment?

A: No. The MAN MM2-4TX1 is an unmanaged physical interface expansion module. All managed switch features (VLANs, SNMP, Hiper-Ring) are handled directly by the main MICE switch engine (e.g., / base software).

Q: How do I know if I need the vs an optical fiber module like the MM3-2FX/2TX?

A: The is strictly for copper drops (4 x RJ45) up to 100 meters. If you need to span long distances between cabinets without electromagnetic interference, you will need a media module that includes fiber optic ports (FX).

Q: Are these modules original OEM Hirschmann parts?

A: Yes, we supply genuine Hirschmann (Belden) hardware sourced through factory surplus, panel upgrades, and verified industrial liquidations.

Q: What warranty coverage comes with surplus or discontinued Hirschmann cards?

A: Every module comes backed by our full 12-month functional replacement warranty. If a port fails or the card drops off the backplane bus, we replace it or refund it immediately.
