Description
Core Product Summary
The Matrox ET-436-A-FX-R2-SR-16GB-NOV is a high-performance IP KVM transmitter module from the Matrox Extio 3 Series (Extio N3408 architecture). Designed for secure, low-latency remote operation in critical control room environments, this unit captures multi-display computer workstation outputs—supporting up to four 1080p displays or a single 4K60 4:4:4 video feed—and transmits them over standard 10GbE or 1GbE IP networks via fiber-optic SFP+ transceivers.
Built for continuous industrial, broadcast, energy, and defense control room deployments, the transmitter processes keyboard, video, mouse, USB 2.0, and analog audio signals with minimal latency. It incorporates Matrox’s proprietary ultra-low bitrate compression technology, enabling high-quality, pixel-perfect desktop extension over LAN or WAN infrastructure without consuming excessive network bandwidth.
Key Technical Specifications
| Specification | Verified Value / Parameter |
| Brand / Manufacturer | Matrox Graphics / Matrox Video |
| Product Family | Extio 3 Series (Extio N3408 Architecture) |
| Model / Part Number | ET-436-A-FX-R2-SR-16GB-NOV |
| Device Type | IP KVM Extender Transmitter Unit |
| Maximum Video Resolution | Single 3840×2160 @ 60Hz (4K60 4:4:4), or Quad 1920×1080 @ 60Hz |
| Video Inputs | 4× Mini-DisplayPort (mDP) 1.2 |
| Network / Fiber Interface | 1× 10GbE / 1GbE SFP+ optical transceiver slot (FiberFX model variant) |
| Fiber Transceiver Type | Short-Range (SR) Multimode SFP+ module included |
| Memory Configuration | 16 GB internal memory architecture |
| Audio Connections | 2× 3.5mm analog audio jacks (Line In / Line Out) |
| USB / Peripheral Support | USB 2.0 pass-through for keyboard, mouse, and peripheral extension |
| Operating Power | External 12 VDC power supply adapter |
Detailed Product Overview
The Matrox ET-436-A-FX-R2-SR-16GB-NOV serves as an essential hardware extension endpoint in high-security, high-density control room installations. By separating user workstations and host PCs from operator desks, facilities can centralize noisy, heat-generating computer hardware in secure server rooms while providing operators with uncompromised, real-time desktop performance at remote consoles.
Utilizing Matrox’s advanced IP encoding technology, the Extio 3 transmitter compresses multi-stream DisplayPort video and USB peripherals into a low-bandwidth IP stream that travels over standard fiber-optic network infrastructure. The inclusion of a Short-Range (SR) SFP+ optical module allows secure, galvanically isolated signal transmission across multimode fiber links, immune to electrical noise and ground loops common in industrial plants.
System integrators can deploy Extio 3 units as direct point-to-point extenders or integrate them into a managed matrix switching architecture using standard COTS (commercial off-the-shelf) network switches and the Matrox Extio Central Manager software.
Dimensions, Mounting & Connection Notes
- Physical Form Factor: Compact desktop enclosure; can be rack-mounted using optional Matrox Extio 3 rack-mount shelves (up to two units in 1U space).
- Host Video Wiring: Connect mini-DisplayPort cables from the workstation GPU to the four mDP input ports on the transmitter’s rear panel.
- Fiber Network Link: Insert the included SR multimode SFP+ transceiver module into the SFP+ cage and connect LC multimode fiber cabling to the IP network or direct receiver link.
- Cooling & Airflow: Ensure adequate ventilation around the unit when installing in high-density server racks to maintain operation within rated thermal limits.
ET-436-A-FX-R2-SR-16GB-NOV
ET-436-A-FX-R2-SR-16GB-NOV
System Compatibility & Integration Requirements
| Item / Dependency | Verified Compatibility or Requirement | Practical Note |
| Receiver Compatibility | Matrox Extio 3 Series Receiver Units (e.g., ER-436 Series) | Pairs across 1GbE or 10GbE IP networks for KVM extension |
| Network Infrastructure | Standard 1GbE or 10GbE managed network switches | Requires IGMP snooping and jumbo frame support for matrix configurations |
| Host PC Interface | PC graphics card with 4× DisplayPort / Mini-DisplayPort outputs and USB 2.0 port | Connects via supplied mDP-to-mDP video cables and USB host cable |
| Management Software | Matrox Extio Central Manager | Enables centralized device configuration, routing, and access control |
| Power Supply | Included 12 VDC external power adapter | Ensure dedicated power connection at the host server rack |
FAQ
What is the Matrox ET-436-A-FX-R2-SR-16GB-NOV?
It is a high-performance IP KVM transmitter module from the Matrox Extio 3 Series designed to extend quad 1080p or single 4K60 video, audio, and USB signals over fiber-optic networks.
What video resolutions does this transmitter support?
It supports either a single 4K UHD (3840×2160 @ 60Hz) display or up to four simultaneous Full HD (1920×1080 @ 60Hz) displays over a single network connection.
What fiber-optic connection does this model variant use?
The “FX-R2-SR” designation indicates a fiber-optic SFP+ network connection equipped with a Short-Range (SR) multimode optical transceiver module.
How does this unit connect to the host computer?
It connects to the host computer via four Mini-DisplayPort video inputs, a USB 2.0 host connection, and 3.5mm analog audio cables.
Can it be used in a matrix switching setup?
Yes, using standard managed 1GbE/10GbE network switches and Matrox Extio Central Manager software, multiple Extio 3 transmitters and receivers can form a scalable IP KVM matrix system.
