Description
Product Introduction
The Schneider Electric Modicon 140CPU65160 is a premier single-slot CPU designed for the Modicon Quantum PLC platform. Built specifically to run on Schneider’s Unity Pro (now EcoStruxure Control Expert) programming architecture, it replaces older Concept/ProWORX processors with significantly increased processing speed, expanded memory capacity, and modern interface options.
Featuring an onboard 10/100 MBit/s Ethernet port (supporting Modbus TCP/IP and HTTP web server functions), a USB programming port, and a built-in diagnostics LCD keypad, the 140CPU65160 eliminates the need for separate network coprocessor cards in many control schemes. It handles high-density local and distributed I/O across large-scale continuous process networks with minimal scan overhead.
Key Technical Specifications
| Parameter | Specification Details |
| Module Type | Central Processing Unit (CPU) |
| Part Number | 140CPU65160 |
| Manufacturer | Schneider Electric / Modicon |
| Platform Compatibility | Modicon Quantum Automation Series Backplanes |
| Programming Software | Unity Pro / EcoStruxure Control Expert (v3.0 or higher) |
| Processor Type | 32-Bit RISC (266 MHz) |
| User Memory | 1024 KB Internal RAM (Expansion via PCMCIA card supported) |
| Execution Speed | 0.045 µs per Boolean instruction / 0.06 µs per Word instruction |
| Communication Ports | 1x Ethernet 10/100 Base-TX (RJ45), 1x USB Type-B, 1x Modbus RS-232/485 (DB9) |
| Diagnostic Display | Backlit LCD Display + Keypad (4 lines, 16 characters) |
| Bus Current Requirement | ~2.56 A max at 5.1V DC (from backplane) |
| Backup Battery | 3.6V Lithium Cell |
Application Scenarios & Field Experience
The 140CPU65160 is engineered for enterprise-level automation, plant-wide SCADA integration, and multi-axis or high-speed process loops.
- Refinery & Petrochemical Tank Farms: Managing thousands of I/O points across Ethernet/IP or Modbus TCP networks with real-time web diagnostic access.
- Large Municipal Wastewater Treatment: Coordinating multiple aeration basins, digesters, and lift stations using embedded Modbus TCP peer-to-peer messaging.
- Pharmaceutical Batch Processing: Utilizing 1024 KB application memory to execute complex sequential function charts (SFC) and extensive recipe libraries.
- Mining & Bulk Material Handling: Handling fast interlocking logic for long overland conveyors and automated stacker-reclaimers.
Field Case Study: A chemical processing facility was upgrading an aging Modicon 140CPU43412A system to modern Modbus TCP networking. By dropping in a 140CPU65160, the engineering team gained native 10/100 Ethernet without occupying extra backplane slots for an NOE module. Program scan time plummeted from 28 ms to under 4 ms, providing smoother valve response and tighter temperature control on their main reactor.
140CPU65160
140CPU65160
140CPU65160
Quality Assurance & Testing Procedure
Every surplus 140CPU65160 processor undergoes a complete live-rack diagnostic test prior to dispatch:
- Visual & Structural Audit: Inspecting backplane pins, housing latches, front LCD screen contrast, and USB/Ethernet port connectors.
- Backplane Power-On Diagnostics: Seated in a Quantum test chassis to verify power distribution, 5.1V bus load, and proper boot execution on the LCD panel.
- Unity Pro Logic & Memory Benchmark: Programmed via USB using EcoStruxure Control Expert to verify full 1024 KB internal RAM, execution speed, and battery backup memory retention.
- Ethernet & Serial Communication Test: Stress-testing the onboard Ethernet port under heavy Modbus TCP traffic and confirming USB connection stability.
- ESD-Safe Packaging: Fitted with a fresh 3.6V lithium backup battery, static-shielded, and packaged in custom protective foam.
Technical Field Tips & Traps
- ⚠️ High Backplane Current Draw: The 140CPU65160 draws up to 2.56 Amps of 5.1V DC power from the Quantum backplane—more than double older CPU models. Ensure your rack power supply (such as a 140CPS11420 or 140CPS21400) has enough headroom, or add a secondary summable power module.
- ❗ PCMCIA Expansion Card Requirement: While the unit features 1024 KB of built-in RAM, loading large Unity Pro application files with embedded documentation or extended historical data logs may require an optional PCMCIA memory expansion card (e.g., 140XCP51000).
- ⚠️ Unity Pro / EcoStruxure Only: Unlike older Quantum CPUs (like the 140CPU11303), the 140CPU65160 cannot be programmed with legacy ProWORX or Concept software. You must use Unity Pro / EcoStruxure Control Expert.
- ❗ Ethernet IP Address Setup via BOOTP / DHCP or LCD: The front-panel LCD and keypad allow technicians to view and manually set the Ethernet IP address directly at the rack, eliminating the need to connect via serial just to establish an initial network connection.
Frequently Asked Questions
Q: Can I upgrade directly from a 140CPU43412A to a 140CPU65160?
A: Yes, physically it fits into the exact same Quantum slot. However, you must convert the application project from Concept/ProWORX to Unity Pro (EcoStruxure Control Expert) and adjust the hardware configuration accordingly.
Q: Does the embedded Ethernet port on the 140CPU65160 support Hot Standby (CHS)?
A: For full Hot Standby redundancy, specific Hot Standby Quantum CPUs (such as the 140CPU65260 or 140CPU65160S) or additional coprocessors are typically paired with the 140CHS11000 module.
Q: What cable is used to program the 140CPU65160?
A: Programming can be done quickly using a standard USB Type-A to Type-B cable connected to the front panel, or over the network via an Ethernet cable using Modbus TCP.
Q: What is the purpose of the front panel LCD display?
A: The LCD display allows real-time viewing of CPU operating status, diagnostic fault codes, IP address configuration, firmware version, and battery health without plugging in a laptop.
