3. Key Technical Specifications
| Parameter | Value |
|---|---|
| Application | Overhead and cable feeder protection |
| Protection | Directional/non-directional overcurrent, earth-fault, voltage |
| Communication | IEC 61850 with GOOSE, optional protocols |
| Power Supply | Standard 24-250 V DC / 100-240 V AC range |
| Operating Temperature | -25°C to +55°C |
| Housing | Withdrawable unit, compact design |
| I/O Configuration | Multiple binary inputs/outputs per variant |
| Measurement | Phase currents, voltages, power, frequency |
| Fault Recording | Disturbance recorder with waveform capture |
| Setting Groups | Multiple independent groups |
4. Product Introduction
The ABB REF615 HBFEAEAGNDA1ABA1XG is a dedicated feeder protection and control IED for utility and industrial distribution systems. It handles protection of overhead lines and cable feeders in radial, looped, or meshed networks.
This version includes advanced communication and protection functions suitable for modern substations. It offers fast fault clearing, integrated control, and seamless IEC 61850 integration. Verify the full order code matches your required hardware and software options before installation.
- REF615 HBFEAEAGNDA1ABA1XG
- REF615 HBFEAEAGNDA1ABA1XG
5. Troubleshooting Quick Reference
| Symptom | Possible Cause | Relevance to this Part | Quick Check Method | Recommendation |
|---|---|---|---|---|
| No power or HMI | Supply voltage missing | ❌ Low | Measure at power terminals | Confirm supply voltage and polarity |
| Protection not tripping | CT/VT input or setting issue | ✅ High | View analog values in relay HMI | Check wiring polarity and scaling |
| No GOOSE communication | Network configuration | ✅ Medium | Check Ethernet status and subscriptions | Verify SCD file and port settings |
| Output contacts not closing | Logic or wiring fault | ✅ High | Monitor virtual outputs and physical status | Test trip circuit supervision |
| Inaccurate measurements | Sensor or calibration problem | ✅ Medium | Compare with independent meter | Inspect secondary circuits |
Export disturbance records if the issue continues and provide them to technical support.
6. Frequently Asked Questions (FAQ)
Is the REF615 hot-swappable? The withdrawable design allows unit exchange with power off. Never insert or remove under load. Follow proper isolation procedures.
What condition is the unit? New Original / New Surplus. Each unit undergoes visual inspection, power-on tests, and communication verification. Test documentation available upon request.
Will this exact code replace my existing REF615? Match the full order code including hardware and communication options. Differences in I/O or protocol support can prevent direct compatibility.
How do I prepare for replacement? Backup the existing configuration using PCM600. Photograph all rear terminal connections. Note current setting groups and parameters. Restore and test thoroughly after swap.
What warranty do you offer? 1-year functional warranty. Does not cover damage from incorrect handling, wiring errors, or external surges.
Why purchase surplus for critical protection relays? Immediate availability versus long factory lead times. These are authentic ABB units with full remaining service life at lower cost.
Common installation pitfalls? Wrong CT polarity leads to false or missed trips. Ensure proper grounding of communication ports. Validate all protection elements and logic in test mode before energizing the primary circuit. A mismatched SCD file has delayed many IEC 61850 projects.
