The Applied Materials 0190-07970 is a legacy Producer SE CH interlock module associated with the CDN500-19 assembly. Available parts references consistently classify the item as a PCB/interlock module rather than a general-purpose PLC I/O card.
This distinction is important in semiconductor-tool maintenance. An interlock board participates in equipment permissive and protection circuitry, so an apparently functional replacement still needs to be validated in the correct tool configuration. Publicly available information on this exact AMAT part is limited, and some reseller listings conflict on its function; therefore, the identification as a Producer SE CH Interlock Module / CDN500-19 is considerably better supported than speculative electrical specifications.
Technical Specifications
| Specification | 0190-07970 |
|---|---|
| Manufacturer | Applied Materials |
| Part Number | 0190-07970 |
| Module designation | Producer SE CH Interlock Module |
| Associated model | CDN500-19 |
| Component category | PCB / interlock module |
| Known board identifier | DIP-378-020 |
| Related identifiers | DIP498 15049804; CDN497 15049704 |
| Application family | Applied Materials Producer equipment |
| Approx. listed weight | 0.49–0.50 kg |
| Public electrical specifications | Not sufficiently verified |
The 0.49–0.50 kg figure appears in secondary-market listings, while the identification codes are also documented by parts suppliers.
Important Specification Warning
There are online listings that claim detailed values such as 24 VDC input, 16 digital inputs, eight relay outputs, RS-485/EtherCAT communication, and specific response times for the 0190-07970. Those claims are not supported by a primary Applied Materials or MKS technical document located in the available search results.
For procurement and engineering documentation, I would not treat those values as verified specifications.
The safest technical identification is:
AMAT 0190-07970 — Producer SE CH Interlock Module, CDN500-19
Field Application & “Trench” Experience
Example: Producer Tool Interlock Fault
A legacy Producer system develops an intermittent equipment-permissive fault. The tool reports an interlock-related condition even though the operator cannot reproduce an obvious chamber fault.
A technician should not immediately assume that the 0190-07970 board has failed.
A disciplined troubleshooting sequence would be:
- Capture the exact tool alarm and interlock state.
- Check the equipment maintenance history for recurring interlock events.
- Verify external permissive conditions and associated wiring.
- Inspect connectors and board seating.
- Check the board for contamination, corrosion, damaged components, or previous repair work.
- Compare the interlock state with a known-good machine or documented normal state.
- Substitute a correctly identified 0190-07970 only after the external interlock chain has been verified.
- Perform the equipment manufacturer’s required interlock validation after replacement.
This matters because an interlock PCB can report the result of a downstream fault without being the original cause.
Niche Applications
- Producer semiconductor deposition equipment — maintaining legacy equipment-control interlock circuitry.
- 300 mm wafer-fab tool maintenance — retaining an exact board-level spare for older AMAT installations.
- High-value semiconductor equipment refurbishment — restoring equipment where original OEM board availability is limited.
0190-07970
0190-07970
QA & Testing SOP
For this particular part, procurement quality control should focus heavily on exact identification and tool-specific testing.
Recommended Incoming Inspection
1. Verify the OEM number
Confirm:
0190-07970
Do not accept a board solely because it is described as an “AMAT interlock board.”
2. Verify secondary identification
Where applicable, compare the board against the documented:
- CDN500-19
- DIP-378-020
- DIP498 15049804
- CDN497 15049704
These identifiers appear in secondary-market documentation associated with 0190-07970.
3. PCB inspection
Check for:
- Corrosion
- Burn marks
- Cracked solder joints
- Damaged connectors
- Bent pins
- Missing components
- Evidence of unauthorized repair
- Electrolytic capacitor deterioration
4. Functional test
Ideally, test the module using an appropriate CDN500-19 / Producer-equipment test fixture or installed-equipment procedure.
A generic bench power-up is not sufficient to establish interlock functionality.
5. Record condition
Classify the unit explicitly as:
- New Surplus
- New Open Box
- Refurbished
- Working Used
- Untested / As-Is
This distinction is particularly important for safety- or interlock-related semiconductor-tool hardware.
⚠️ Veteran’s Tech Trap Guide
⚠️ Trap 1 — Confusing the part with a generic safety relay
The 0190-07970 is identified as a Producer SE CH Interlock Module / PCB. It should not be treated as a generic replacement safety relay or PLC interlock module.
⚠️ Trap 2 — Buying by appearance
Legacy AMAT boards can have visually similar connectors, board dimensions, and component layouts.
Match the complete part number and board identifiers.
A board that physically fits does not necessarily belong to the same equipment configuration.
⚠️ Trap 3 — Accepting unsupported specifications
Several reseller pages publish detailed electrical specifications for this part, but those specifications are inconsistent with the more reliable identification records.
PRO TIP: For an AMAT interlock board, require an actual board photograph showing the OEM label and revision before issuing a PO. If the supplier cannot provide the label, treat the part-number identification as unverified.
Lifecycle & Spare-Inventory Strategy
The 0190-07970 is best treated as a legacy semiconductor-equipment spare. Public availability is primarily through specialized semiconductor-equipment parts suppliers rather than normal OEM distribution. Current listings show examples ranging from used working units to untested/as-is boards.
For critical Producer tools, inventory management should prioritize:
- Exact OEM part-number control.
- Board revision tracking.
- Known-good tested spares.
- ESD-controlled storage.
- Anti-static packaging.
- Supplier test documentation.
- Tool compatibility verification.
- Separate inventory classification for tested and untested boards.
For an expensive semiconductor tool, carrying one tested interlock-board spare can be economically justified if the alternative is extended equipment downtime and difficult sourcing.
Dynamic FAQ
What is AMAT 0190-07970?
It is an Applied Materials Producer SE CH Interlock Module, associated with equipment. Multiple independent parts references identify it this way.
What equipment is it associated with?
Available documentation associates 0190-07970 with Applied Materials Producer equipment, specifically the interlock module designation.
Is 0190-07970 a PLC module?
No. It is identified as a PCB/interlock module for semiconductor manufacturing equipment, not as a conventional Schneider, Siemens, or Allen-Bradley PLC I/O module.
Is 0190-07970 still available?
Secondary-market availability exists. Current listings show used and surplus examples, although condition and warranty vary significantly.
Can a used 0190-07970 be installed directly?
It should only be installed after verifying the exact board identification, revision/configuration requirements, physical condition, and applicable Producer equipment maintenance procedure. Interlock circuitry should be functionally validated after replacement.
What warranty should I expect?
There is no single standardized secondary-market warranty. For example, one supplier lists a working-surplus unit with a 90-day warranty, while another lists used units with a 30-day satisfaction guarantee.
Ask the supplier to state the warranty and test status explicitly on the quotation.
Bottom Line
Applied Materials 0190-07970 is identified as a Producer SE CH Interlock Module associated with CDN500-19. The strongest available evidence supports its identification as an AMAT interlock PCB, with related identifiers including DIP-378-020, DIP498 15049804, and CDN497 15049704.
For procurement, the critical controls are exact OEM identification, board-revision verification, ESD-safe handling, documented testing, and post-installation interlock validation. I would avoid publishing unverified electrical ratings for this part unless an OEM schematic, manual, or board documentation is available.
