The GE IS200BPVCG1BR1 is an IS200-series board associated with GE’s Mark VI turbine-control platform. The BPVC board designation and complete revision string are important when identifying the correct replacement for an installed control rack.
In field service, this is not a board to select by appearance alone. Mark VI VME hardware can share mechanical characteristics while performing different electrical functions. Before replacement, verify the complete part number, board revision, rack location, connectors, jumper settings, and system documentation.
Technical Specifications
- Manufacturer: General Electric
- Part Number: IS200BPVCG1BR1
- Product Family: IS200
- Control Platform: Mark VI
- Board Designation: BPVC
- Product Type: VME interface/backplane board
- Architecture: VME-based GE turbine-control system
- Primary Application: Mark VI control equipment
- Board Revision: G1B
- Revision/Variant: R1
- Installation: Mark VI control rack
- Replacement Strategy: Exact part-number matching
Technical caution: Exact electrical specifications for the IS200BPVCG1BR1 should be verified against the GE Mark VI documentation for the applicable rack. Do not infer connector pinouts, VME bus characteristics, power requirements, jumper settings, or slot assignments from another IS200 board.
Field Application & the “Trench” Experience
A Mark VI control rack starts reporting intermittent communication faults during a turbine maintenance window. The initial suspicion is a processor or I/O module, but the fault follows the rack interface during troubleshooting.
The maintenance engineer checks the installed board and finds IS200BPVCG1BR1. A spare BPVC board is available, but the team does not simply swap it because the board “looks identical.” They verify the full part number, revision, rack position, connectors, and configuration before proceeding.
After installation, the rack is checked systematically rather than immediately returning the turbine to service.
That is the right workflow for legacy VME control hardware. One incorrect board can create a confusing rack-level fault.
Specific application scenarios
- Mark VI VME rack maintenance — replacement of a suspected BPVC interface/backplane board.
- Turbine-control communication troubleshooting — investigating rack-level communication or interface abnormalities.
- Mark VI critical-spare management — maintaining an exact IS200BPVCG1BR1 spare for an operating turbine-control system.
IS200BPVCG1BR1
Transparency SOP: QA & Testing
For New Surplus or Refurbished IS200BPVCG1BR1 inventory, testing should address both physical condition and electrical integrity.
QA checklist
- Part-number verification: Confirm
and all board markings. - PCB inspection: Check for corrosion, contamination, cracked solder joints, damaged traces, and thermal discoloration.
- Connector inspection: Examine VME and other board connectors for oxidation, bent contacts, contamination, or mechanical damage.
- Configuration check: Record jumpers, switches, revision markings, and board modifications.
- Component inspection: Check visible capacitors, ICs, resistors, semiconductors, and other components.
- Electrical testing: Perform appropriate continuity, isolation, and power-path checks.
- Functional testing: Where suitable Mark VI test equipment is available, verify board operation under controlled conditions.
- Final QC: Document test results, repair history, condition, and warranty.
Important: A board that passes a visual inspection has not necessarily passed a functional Mark VI test.
The Veteran’s Tech Trap Guide
⚠️ Trap #1 — Confusing BPVC with another IS200 rack board
IS200 boards can look very similar. The board designation and complete part number matter.
PRO TIP: Use exactly as the procurement identifier and compare it against the original board.
⚠️ Trap #2 — Ignoring the revision
The G1B and R1 identifiers should be retained in maintenance records. Do not assume another BPVC revision is a direct replacement without verification.
⚠️ Trap #3 — Mishandling VME connectors
Repeated insertion and removal can damage connector contacts. Keep the board aligned correctly and avoid forcing the PCB into the rack.
⚠️ Trap #4 — ESD during board replacement
Mark VI electronics should be handled using appropriate ESD controls. Grounding, antistatic packaging, and controlled work surfaces are inexpensive compared with replacing a damaged control board.
⚠️ Trap #5 — Forgetting rack configuration
Before removal, document the slot location, connector arrangement, board markings, and configuration hardware. Do not rely on memory after the rack has been disturbed.
Dynamic FAQ
What is the GE ?
The is a GE IS200-series VME interface/backplane board associated with the Mark VI turbine-control platform.
What system uses the ?
It is associated with GE Mark VI turbine-control equipment and its VME-based control-rack architecture.
Is the a conventional I/O module?
No. It should be treated as rack/interface hardware rather than a conventional analog or discrete I/O module.
Can another BPVC board replace it?
Not automatically. Verify the complete part number, revision, rack slot, connector arrangement, configuration, and applicable Mark VI documentation before substitution.
What should I provide when requesting a quotation?
Provide the full number, clear photographs of the installed board, revision markings, rack information, and any GE Mark VI drawings or documentation available.
What does New Surplus mean?
New Surplus generally means unused inventory outside the manufacturer’s current production or normal distribution channel. It does not necessarily indicate a recent manufacturing date.
What does Refurbished mean?
Refurbished generally means previously used or returned hardware has been inspected and may have been repaired and function-tested. The supplier should state the actual refurbishment and testing performed.
Should a New Surplus be tested?
Yes. Long-term storage can affect electronic components and connectors even when a board has never been installed. Inspection and controlled testing are appropriate before placing the board into a critical Mark VI control rack.
What warranty should I request?
Confirm the warranty period, covered failures, return procedure, and exact condition of the supplied board. New Surplus, Refurbished, and Repaired units should have clearly stated terms. A supplier warranty should not be presented as a GE factory warranty unless that status is documented.
